Arduino Nano with RC522 RFID Reader | DIY Access Control System

12 Nov, 2024
Posted by: BATFLAP TECH PVT LTD Admin

In the world of DIY electronics, security and access control are exciting areas to explore. Today, we’re diving into a project that brings these features to life: the Arduino Nano paired with the RC522 RFID Reader. Together, these components allow you to create an RFID-based access control system that’s both compact and powerful. Whether you want to control access to a room, log attendance, or create custom RFID applications, this project opens up numerous possibilities.

Understanding the RC522 RFID Reader

The RC522 RFID Reader is a popular choice for RFID projects due to its affordability and ease of use. It operates at 13.56 MHz and communicates with the Arduino via the SPI protocol. With this module, you can read and write data to RFID tags, making it ideal for secure access and tracking projects.

Key features of the RC522 RFID Reader:

Wide Compatibility: Works with various RFID cards and tags.
SPI Communication: Offers fast data transfer between the module and microcontroller.
Efficient Power Use: Operates on low power, ideal for portable setups.

Components Needed

To build this project, you’ll need the following components:

Arduino Nano: The microcontroller handling all operations.
RC522 RFID Reader Module: The reader to scan RFID tags.
RFID Tags: Cards or key fobs compatible with the RC522.
Connecting Wires
Breadboard (optional)

Setting Up Arduino Nano with RC522

Step 1: Wiring the Components

To connect the RC522 RFID Reader to the Arduino Nano, follow this wiring guide:

RC522 Pin	Arduino Nano Pin
VCC	3.3V
RST	D9
GND	GND
MISO	D12
MOSI	D11
SCK	D13
SDA	D10

Step 2: Installing the MFRC522 Library

The MFRC522 library simplifies interaction with the RFID module. Install it directly from the Arduino IDE:

Go to Sketch > Include Library > Manage Libraries.
Search for MFRC522 and click Install.

Step 3: Uploading the Code

You can find the detailed schematic and code for this project on our GitHub page:
GitHub Repository

Applications of Arduino Nano and RC522 RFID Reader

Now that your RFID reader is working, here are some ways you can use it:

Secure Access Control: Restrict access to rooms, lockers, or other secure areas.
Attendance System: Track entries and exits for employees, students, or event attendees.
Inventory Management: Track items with unique RFID tags.

Real-World Applications

By using the Arduino Nano with the RC522 RFID Reader, you can create a variety of useful and practical systems. Here are a few ideas to get you started:

Digital Door Lock: Grant access only to authorized users by linking the RFID system to a servo motor or electronic lock.
Time and Attendance: Automatically log entries and exits by scanning RFID tags.
Asset Management: Track inventory by assigning an RFID tag to each item and scanning it during check-in and check-out.

YouTube Demo

For a quick video demonstration of this project, check out our YouTube Shorts:

🔗 YouTube Shorts: Arduino Nano with RC522 RFID Reader | Creating a Basic Access System
#kitkraftindia

Conclusion

The combination of an Arduino Nano with an RC522 RFID Reader opens up endless possibilities for access control and RFID applications. With simple wiring and easy-to-use libraries, you can bring the power of RFID into your next project.
