Build an Arduino LED Dice with MPU6050 & MAX7219 | DIY Motion-Sensing Dice

When it comes to learning and experimenting with electronics, nothing beats the excitement of building your own DIY projects. In this blog, we’ll guide you through creating an Arduino-based LED Dice that uses an MPU6050 accelerometer and a MAX7219 LED matrix to simulate a dice roll when shaken. This project is perfect for beginners and advanced makers looking to explore motion sensing and LED displays!

What is a Motion-Sensing LED Dice?

A traditional dice requires a roll, but in this project, we replace physical rolling with motion sensing! The MPU6050 accelerometer detects movement, and the Arduino Nano processes the data to generate a random number. This number is then displayed on the MAX7219 LED matrix, mimicking a real dice roll.

This project introduces motion detection, random number generation, and LED matrix control, making it an excellent hands-on learning experience for electronics and coding enthusiasts.

Components You’ll Need

To get started, gather the following components:

• Arduino Nano

• MPU6050 Accelerometer

• MAX7219 LED Matrix

• Breadboard

• Jumper Wires

• USB Cable for Arduino

All these components are readily available at KitKraft.in. Order now and start building your project today!

How Does It Work?

• MPU6050 Accelerometer: Detects movement when the dice is shaken and sends data to the Arduino.

• Arduino Nano: Processes the accelerometer data and generates a random number between 1 and 6.

• MAX7219 LED Matrix: Displays the generated number, simulating a real dice roll.

This combination creates an interactive electronic dice that reacts to motion, making it a great alternative to physical dice in board games, experiments, and fun DIY projects!

Circuit Diagram and Wiring

Here’s how you can wire up your components:

MPU6050 Accelerometer:

• VCC → Connect to 3.3V on the Arduino

• GND → Connect to GND on the Arduino

• SCL → Connect to A5 (I2C Clock)

• SDA → Connect to A4 (I2C Data)

MAX7219 LED Matrix:

• VCC → Connect to 5V on the Arduino

• GND → Connect to GND on the Arduino

• DIN → Connect to D5

• CS → Connect to D6

• CLK → Connect to D7

Ensure all connections are secure and double-check your wiring before powering up the circuit.

Code for Arduino

Copy and upload the code to your Arduino Nano using the Arduino IDE. You can find the complete source code on our GitHub repository:
🔗 GitHub Link

Applications of This Project

• Board Games: Replace traditional dice with a digital version.

• STEM Learning: Teach students about motion sensors and LED matrix displays.

• Gaming Projects: Integrate motion-based random number generation into creative projects.

Watch It in Action

Check out our YouTube Shorts video showcasing the project: Watch Now.

Get Started Today!

You’ve now learned how to build an Arduino LED Dice with MPU6050 & MAX7219! This project is an excellent way to enhance your skills in electronics, motion sensing, and programming.

To make your experience even better, all the components are available at KitKraft.in. Shop now and bring your ideas to life!

For more exciting projects and tutorials, follow Kitkraft on social media and subscribe to our newsletter.

Happy making! 🎲✨
